REGUPOL sound and drain 22

Impact sound insulation

REGUPOL sound and drain 22

Impact sound insulation

The 15 mm thick impact sound insulation REGUPOL sound and drain 22 has a profiled underside and is ideally suited to a wide range of outdoor constructions on terraces, loggias, roofs and balconies.

REGUPOL sound and drain 22 is a versatile, 15 mm thick impact sound insulation layer with a profiled underside and a low dynamic stiffness of ≤ 21 MN/m3 which is used in a wide range of constructions on roofs and terraces. Depending on the specific build-up, the impact sound reduction value achieves between ∆Lw ≥ 28 dB and ∆Lw ≥ 37 dB.

REGUPOL sound and drain 22
Cradle to Cradle Certified® Bronze

Realised projects with REGUPOL sound and drain 22

Convinced customers all over the world are the best testimony to quality and experience. Here we show a selection of our projects that have been implemented with REGUPOL sound and drain 22 impact sound insulation.

Ikea West Station Vienna

Ikea West Station Vienna

With its greened facades, multi-purpose use and, above all, activated Vienna's new IKEA close to the West Station railway station is much more than just a furniture store, but a new meeting place in the heart of the Austrian capital. Besides the facades, the roof is the special…

read more
Lindley Lindenberg Frankfurt

Lindley Lindenberg Frankfurt

With the Lindley Lindenberg, the Lindenberg Group has created a boutique hotel of a special kind in Frankfurt's east. What awaits visitors here is unique and unconventional. In addition to individually designed rooms, the hotel offers several common areas ranging from a kitchen…

read more
Volkstheater Munich – conversion of the Viehhof site

Volkstheater Munich – conversion of the Viehhof site

After almost four decades in a converted multi-purpose hall, the city of Munich needed a new Volkstheater. At the old location in Brienner Straße, near the main railway station, a lot of improvisational talent was required over the years. In addition to the hall, other buildings…

read more
Mixed-use high-rise Marienturm in Frankfurt's banking district

Mixed-use high-rise Marienturm in Frankfurt's banking district

The Marienturm in Frankfurt am Main is a 155-metre, 38-storey tower and part of a building ensemble on Marieninsel, which also includes the Marienforum and Marienplatz. The design for the Marienturm was created by the architectural firm Müller Reimann Architekten. From 2015 to…

read more
Educational Campus Urban Lakeside Aspern Vienna

Educational Campus Urban Lakeside Aspern Vienna

Campus Seestadt was built on the former Aspern airfield in Vienna and opened in September 2015. The building complex houses a kindergarten, an all-day school, basic support classes and classes for children with disabilities. The educational campus focuses on integration and…

read more
Senior Citizens' Residence Herbstwiesen Kümmersbruck

Senior Citizens' Residence Herbstwiesen Kümmersbruck

In the heart of Kümmersbruck, a neighbouring municipality of Amberg in Bavaria, Germany, a senior citizens' housing complex with 26 residential units and a service centre with a pharmacy and medical care was built right next to the town hall. The project, called Herbstwiesen…

read more
Impact sound insulation for terraces – Education Campus Aron Menczer Vienna

Impact sound insulation for terraces – Education Campus Aron Menczer Vienna

On the Aspang grounds in Vienna's third district, a new educational campus for up to 1,350 children is set to open in 2021. The campus is named after the charismatic Jewish educator Aron Menczer and is divided into two building sections that are connected up to the third floor.

read more
Modern housing development NEO Munich

Modern housing development NEO Munich

The mixed-use high-rise NEO is located in the Baumkirchen-Mitte district of Munich and combines working and living environments in a very innovative way. The building, which was completed in early 2021, is made up of a base building with high-quality rental flats and a…

read more
Alpine luxury spa in Ischgl sets new standards

Alpine luxury spa in Ischgl sets new standards

The Silvretta Therme in Ischgl opened in winter 2022 after a three-year construction period. Already during the planning phase, the focus was set on a resource-saving construction method. The building was planned and constructed to be as sustainable and energy-saving as possible.…

read more
Creating the future in an urban and lively quarter

Creating the future in an urban and lively quarter

On the former Temmler site in Berg am Laim, Macherei München was officially opened on 27.10.2022 after almost five years of construction. On the formerly industrially used site, a 74,400 m² urban and lively quarter for free design has been created.

The quarter, where work is…

read more

Features


  • CE marking
  • Impact sound reduction ∆Lw ≥ 28 dB to ∆Lw ≥ 37 dB
  • Load bearing capacity up to 50 kN/ m²
  • Compressibility  ≤ 2 mm
  • Protective membrane DIN 18531-2


Technical Specifications


Material

Polyurethane elastomer composite

Dimensions

Length 10,000 mm, width 1,250 mm, thickness 15 mm

Weight per roll

max. 81.0 kg

Weight per m²

max. 6.5 kg

Test reports


REGUPOL – the expert by your side

REGUPOL sound and drain products are monitored by internal quality control and third-party inspections subject to the European Technical Assessment ETA-18/0239, which guarantees reliable planning within the European Economic Area.

In compliance with ETA 18/0239, REGUPOL sound and drain 22 shows ozone, oxidation, hydrolysis and weather resistance. It serves as a protective layer to prevent damage to the roof sealing and has been developed with good drainage properties. For balconies and pergolas, REGUPOL sound and drain 22 can be used in combination with Schöck Isokorb® XT.

REGUPOL sound and drain 22 can be installed under fine chippings with concrete tiles but should be checked for stability on-site prior to installation due to the possibility of different mixtures of fine stone chippings that can have different load bearing capacities. To increase stability, pressure resistant thermal insulation ≥ 300kPa can be used. REGUPOL sound and drain 22 is compatible with various roof sealings containing PVC but needs to be approved in each individual case.
